Technical Specifications
Technical Specifications Characteristics
|
Type Classification |
Cartridge, 105mm, APFSDS-T, C76A1(FP105) |
|
Cartridge Type |
105 mm APFSDS-T |
|
Cartridge Length |
36.5 inches (927mm) |
|
Projectile Weight |
12.7 lbs (5.8 kg) |
|
Projectile Lenght |
18.7 inches (475mm) |
|
Subprojectile Weight |
8.0 lbs (3.6 kg) |
|
Subprojectile Diameter |
1.025 inches (26 mm) |
|
Propellant Charge Weight |
220.0 ozs (6.2 kg) |
|
Propellant type |
M30 triple base |
|
Penetrator Material |
Tungsten alloy |
|
Sabot Material |
Aluminum |
|
Fin Material |
Aluminum |
|
Windshield Material |
Aluminum |
|
Tip Material |
Steel |
|
Bourrelet Material |
Stainless Steel |
|
Obturator Material |
Nylon |
|
Seal Band Material |
Polypropylene |
|
Cannon Used with |
M68,L7 |
Temperature Limits
|
Firing: |
|
|
Lower Limit |
-25 ̊F (-32 ̊C) |
|
Upper Limit |
+125 ̊F (52 ̊C) |
|
Storage: |
|
|
Lower Limit |
-65 ̊F (-53.8 ̊C) |
|
Upper Limit |
+165 ̊F (71.1 C) |
|
Chamber Pressure |
59,600 psi at +70 F̊ |
Packing 1 round per fiber container; 2 containers per wooden box:
|
Weight ( IB) |
132.0 |
|
Cu. Ft. |
3.4 |
|
Packing Box: |
|
|
Weight |
124.0 IB |
|
Dimensions |
47 7/16 X 13 5/16 X 7 1/16 in. |
|
Cube |
2.5 cu ft |
