Technical specifications
|
Caliber |
122m |
|
Length of Rocket with Fuze |
2867.31–2882.60 mm |
|
Weight of Rocket with Fuze |
66.6–66.75 kg |
|
Max Ranges |
20km / 40km |
|
Min Range |
3km |
|
Type of the warhead |
High Explosive (HE) Warhead |
|
Fuze MRV-U |
Impact fuze (with immediate, short and long delay action) |
|
Rocket Motor |
Double-based solid propellant |
|
Weight of the Rocket Motor |
48.2kg |
|
Weight of the Propellant |
20.5kg |
|
Color |
Silver |
Limits of Temperature
|
Storage |
-40°C / +60°C |
|
Fire |
-32C/+50C |
|
Packing |
One rocket and one fuze in wooden box |
